Solar Water Pumping System 55KW 75KW Pump Inverter 220V 380V Solar Water Pump Drive Controller For Water Pump

1.0 piece
MOQ
$724.00(1 - 19 pieces) $696.00(20 - 49 pieces) $668.00(>=50 pieces)
Preis
Solar Water Pumping System 55KW 75KW Pump Inverter 220V 380V Solar Water Pump Drive Controller For Water Pump
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Model Number: GS500-55G/75P-4T
Output Current: 112A
Output Frequency: 0-300HZ
Output Type: AC 380V~480V
Certificate: CE/ISO
Warranty: 2 Years
Application: Solar Water Pumping System
Type: AC Pump Controller
Product name: Solar Pump Inverter 55kw
MPPT( maximum power point tracking): 99% High Efficiency
Input: AC/DC Mixed Input
Protection: IP20 / IP54 / IP65
Display: LED
Keyword: VFD AC Drive
Protection Function: Over-current Protection.overload Protection
OEM: Accept Customization
Grundinformation
Zertifizierung: CE/ISO
Model Number: GS500-55G/75P-4T
Zahlung und Versand AGB
Packaging Details: Carton or Wooden Box
Supply Ability: 5000 Piece/Pieces per Month
Produkt-Beschreibung

55KW 75KW Solar Pump Inverter 220V 380V Solar Water Pump Drive Controller for Water Pump

Product Description

♦ LK-Solar Solar Pump Inverter solar pump inverter

Transfer the solar DC to AC, drivers the water pump to supply water, with the functions of MPPT, water level control, AC/DC switching, fully automatic operation, etc., to control and adjust the whole solar pump system operation.

♦ Techniacl Features solar pump inverter
♦ Autorun function.
♦ Water level sensing function.
♦ AC/DC input, or mixed input.

♦ MPPT function.

♦ RS485 remote monitoring and data logging function.

Model introduction

♦ Model Description solar pump inverter

♦ GS500 Model solar pump inverter

Model No. AC input voltage
(V)		 MPPT voltage range
(Vmp)		 Output power
(KW)		 Input current
(A)		 Output current
(A)
GS500-0.75G/1.5P-4TB 3PH 380-480V
50/60HZ		 350~800V DC 0.75 3.4 2.1
GS500-1.5G/2.2P-4TB 1.5 5 3.8
GS500-2.2G/3.0P-4TB 2.2 5.8 5.1
GS500-4.0G/5.5P-4TB 4.0 10.5 9
GS500-5.5G/7.5P-4TB 5.5 14.6 13
GS500-7.5G/11P-4TB 7.5 20.5 17
GS500-11G/15P-4TB 11 26 25
GS500-15G/18P-4TB 15 35 32
GS500-18G/22P-4TB 18.5 38.5 37
GS500-22G/30P-4TB 22 46.5 45
GS500-30G/37P-4TB 30 62 60
GS500-37G/45P-4TB 37 76 75
GS500-45G/55P-4T 45 92 91
GS500-55G/75P-4T 55 113 112
GS500-75G/90P-4T 75 157 150
GS500-90G/110P-4T 90 180 176
GS500-110G/132P-4T 110 214 210
GS500-132G/160P-4T 132 256 253
GS500-160G/185P-4T 160 307 304
GS500-185G/200P-4T 185 326 350
GS500-200G/220P-4T 200 385 377
GS500-220G/250P-4T 220 430 426
input DC votlage range(VOC) 2S / 2T: 100~450V DC
4T: 250~800V DC
Input Max open circuit voltage (VOC) 2S / 2T: 450V DC
4T: 800V DC
MPPT efficiency >99%
Over-load capacity 150%:60S; 180%:10S; 200%:1S
Ouput frequency 0~300HZ(Default: 50/60HZ)
On grid/Generator input Yes
Automatic switch between on grid/generator Yes
Working temperature -20℃~60℃;
when >45℃ or altitude above 1000m, derating as required
Cooling Method Fan Cooling
Communication port Standard isolater RS-485, Modbus protocol
IP grade Standard:IP20 (can customized IP54 or IP65)
Built-in protection shortage of water protection for deep well,full of water protection for tank, light weak sleep, light intensity wake-up, lightning protection, overvoltage protection, undervoltage protection, overcurrent protection, dry pumping protection, overload protection, phase loss protection, short circuit protection, overheat protection.
Parts Description

solar pump inverter

System Introduction

♦ Complete Solar Sater Pump System: SOLAR PUMP INVERTER
Solar pump inverter, solar water pump, solar panel, solar panel bracket, PV Combiner Box, cable, etc.

♦ Main Application: SOLAR PUMP INVERTER
Farmland irrigation, desert greening, fish farm farming, seawater desalination, animal and plant farming, etc.
