MODEL | FS1500-112 | FS1500-124 | FS1500-148 | FS1500-212 | FS1500-224 | FS1500-248 | ||||||
Output | AC Voltage | 100/110/120VAC | 220/230/240VAC | |||||||||
Rated Power | 1500W | |||||||||||
Surge Power | Load 120~150%(3min.);3000W(3sec;resistive) | |||||||||||
Waveform | Pure Sine Wave(THD<3%) | |||||||||||
Frequency | 50/60Hz ±0.05% | |||||||||||
AC Regulation | ±5% | ±10% | ||||||||||
Power Factor Allowed | COSθ-90°~COSθ+90° | |||||||||||
Standard Receptacles | USA/British/Franch/Schuko /UK/Australia/Universal etc. optional | |||||||||||
LED Indicator | Green for power on, red for faulty status | |||||||||||
USB port | 5V 2.1A | 5V 2.1A | ------ | 5V 2.1A | 5V 2.1A | ------ | ||||||
LCD display | voltage, power, protection status ( optional) | |||||||||||
Remote control function | default | |||||||||||
Remote controller | CR80/CRD80 optional | |||||||||||
Input | No Load Current Draw | ≤1.1A | ≤0.80A | ≤0.70A | ≤1.1A | ≤0.80A | ≤0.70A | |||||
DC Voltage | 12VDC | 24VDC | 48VDC | 12VDC | 24VDC | 48VDC | ||||||
Voltage Range | 10.5~15VDC | 21~30VDC | 42~60VDC | 10.5~15VDC | 21~30VDC | 42~60VDC | ||||||
Efficiency(Typ.) | 89%~93% | |||||||||||
Fuse | 40A×6 | 20A×6 | 10A×6 | 40A×6 | 20A×6 | 10A×6 | ||||||
Remote Control | Function (optional) | |||||||||||
Protection | BAT. Low Alarm | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC | 10.5±0.5VDC | 21±1.0VDC | 42±2.0VDC | |||||
BAT. Low Shutdown | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | 10±0.5VDC | 20±1.0VDC | 40±2.0VDC | ||||||
Over Load | Shut down output voltage , restart to recover | |||||||||||
Over Voltage | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | 15.5±0.5VDC | 31±1.0VDC | 62±2.0VDC | ||||||
Over Temperature | Shut down output voltage , recover automatically after temperature goes down | |||||||||||
Output Short | Shut down output voltage , restart to recover | |||||||||||
DC Input Reverse Polarity | By fuse | |||||||||||
Earth Fault | Shut off o/p when the load has electrical leakage | |||||||||||
Soft Start | Yes, 3-5 Seconds | |||||||||||
Environment | Working Temp. | 0~+50℃ | ||||||||||
Working Humidity | 20~90%RH non-condensing | |||||||||||
Storage Temp.&Humidity | -30~+70℃,10~95%RH | |||||||||||
Safety & EMC | Safety Standards | Certified UL 458(only for "GFCI" receptacles) | Certified EN 60950-1; 2006+A11: 2009+A1: 2010+A12: 2011+A2: 2013. | |||||||||
Isolation Resistance | I/P-O/P:100M Ohms/500VDC | |||||||||||
EMI Conduction & Radiation | Certified FCC class A | Certified EN 62040-2:2006,EN61000-3-2; EN61000-3-3; | ||||||||||
EMS Immunity | ------ | Certified IEC61000-4-3, IEC61000-4-6 | ||||||||||
E-MARK | ------ | Certified ECE RIO.05:2014 | ||||||||||
Others | Dimension(L×W×H) | 325.2×281.3×112.7mm | ||||||||||
Packing | 5.2kg;2pcs/11.1kg/0.053m³ | |||||||||||
Cooling | Load control fan or by thermal control fan | |||||||||||
Application | Home and Office appliances,Portable Power Equipment,Vehicle,Yacht and Off-Gid Solar power systems…etc. |
